Factory High Efficiency Electric Garbage Truck Japan Sweeper Suction Adjustable Speeds
Caratteristiche Galleria Descrizione di prodotto Richieda una citazione
Caratteristiche
Specificazioni
Applicable Industries: Manufacturing Plant, Food & Beverage Factory, Farms, Construction works , Energy & Mining, Other
Showroom Location: None
Video outgoing-inspection: Provided
Machinery Test Report: Provided
Marketing Type: Ordinary Product
Warranty of core components: 1 Year
Core Components: PLC, Engine, Bearing, Gearbox, Motor, Pressure vessel, Gear, Pump
Condition: New
Dimension(L*W*H): 5060*1580*2010mm
Weight: 2320 kg
Warranty: 1 Year
Product name: Street Washing Sweeper Truck
Battery: 41.86 Kwh
Motor: Permanent Magnet Synchronous Motor
Cleaning Process: Water
Water Tank Capacity: 350 L
Speed: ≤80 km/h
Range: ≥260 km
Rated capacity: 390 kg
Gradeability: ≥20%
Charge Time(h): 2 charging methods, fast and slow
Informazioni di base
Termini di pagamento e spedizione
Packaging Details: steel pallet
Supply Ability: 50000 Piece/Pieces per Year
Descrizione di prodotto
Products Description
project name
Performance indicators









Project name
Vehicle model
5030TS
Length*Width*Height(mm)
5060×1580×2010
Maximum Total mass（kg）
2840
Curb weight（kg）
2320
Loading capacity（kg）
390
Battery power(Kwh)
41.86
Driving Mileage(km)
260 (Condition Method)
Gradeability(%)
≥20%
Front/ Rear track(mm)
720/1640
Maximum speed (full load)(km/h)
80
Wheelbase(mm)
2700
Chargeing time(H)
2 charging methods, fast and slow




Special features
Cleaning width (mm)
2100
Cleaning speed (km/h)
5～10
Discharging Angle°
≥48
Cleaning rate (%)
≥98
Water Tank volume (L)
350
Trash can volume (L)
1500
Maximum inhalation particle size (mm)
30





Others
Traction battery
Lithium iron phosphate battery
Driving motor type
Permanent Magnet Synchronous Motor
Light and signal
headlight + turn signal + brake light + fog light + reverse light + electric horn
Tire
175R14LT 8PR
Steering mode
Electric Power Steering
ABS Electronic traction control system
YF8 Model, four-channel type
Suspension system
Longitudinal leaf spring,dependent suspension

Application
This product is light and flexible, the cleaning system can be widely used in the main road, municipal and airport road surface, urban residential areas, parks, back streets and other road cleaning.

Product Characteristics

1. Middle sweeping disc + rear suction nozzle, which has high cleaning efficiency and good road adaptability. 2. Fully floating suction nozzle can automatically level according to the ground conditions, with large cleaning capacity, fast cleaning speed, simple operation and convenient maintenance. 3. The bearings required for the fan are imported bearings, high-power wear-resistant high-pressure centrifugal fans, which have the advantages of low noise, large air volume, high efficiency and long service life. 4. The V-belt connection between the motor and the fan can effectively improve the service life of the motor. 5. The cleaning mechanism is controlled by an oil cylinder, the inclination angle of the swing arm type disc brush is adjustable, the ground pressure of the sweeping disc is adaptively adjusted, and it has the function of automatic reset for obstacle avoidance. 6. The lifting and lowering of the trash cans be controlled by the hydraulic system driven by the electric motor, or the lifting can be controlled by the hand-operated oil pump. 7. The electrical system is controlled by an integrated block, and the LCD screen in the cab displays various parameters. The display screen and the CAN bus of the motor carry out data communication. The electrical wiring harness is reasonably arranged, neat and beautiful. One-button operating system in the cab, easy to operate. 8. One-button operating system in the cab, easy to operate. 9. High-quality originals are used for transmission parts, hydraulic parts and electrical components. 10. Anti-rust treatment of non-stainless steel parts, durable.
